Peony Starch Separator With High Speed And Continuous Nozzle Discharge

چین Peony Starch Separator With High Speed And Continuous Nozzle Discharge تامین کننده

تصویر بزرگ :  Peony Starch Separator With High Speed And Continuous Nozzle Discharge

جزئیات محصول:

Place of Origin: China
نام تجاری: Peony
گواهی: ISO9001&ISO14001,CE
Model Number: PDSS20-30

پرداخت:

Minimum Order Quantity: 1 set
قیمت: USD20000-21000/SET FOB SHANGHAI
Packaging Details: Standard export packing
Delivery Time: 60-90 days after deposit
Payment Terms: TT. LC
Supply Ability: 100sets per month
Contact Now
توضیحات محصول جزئیات
مدل: PDSS20-30 ظرفیت: 20-30m3 / h
قدرت موتور: 30kw تخلیه: تخلیه سرباره مداوم نازل
وزن: 1،327 کیلوگرم MOC: اس اس
یاتاقان: SKF صفحه کنترل: با

Peony Starch Separator With High Speed And Continuous Nozzle Discharge



Description:



The starch separators are disc separators with high speed and continuous nozzle discharge. They are mainly used for protein separation in the starch industry, like corn starch, sweet potato starch, cassava starch and potato starch, etc. for purifying starch, previous concentration, separating protein and recovering starch in starch production and also separating two-phase liquid-solid, recovering concentration or purifying, such as bleaching earth, recovering pulp, waste water, etc.
All the parts of the separator contacting the materials are made of stainless steel, therefore it meets the requirement of food hygiene.
The design production and acceptance check are complied with JB/T6419 "Disc Starch Separator.

Peony Starch Separator With High Speed And Continuous Nozzle Discharge



Technical Parameters:

Model  PDSS20-30
Capacity (m3/h) 20-30
Motor power (KW) 30
Discharge Nozzle continuous slagging
Output pressure  ≤0.2
Weigh (KG)   2150
L(mm) × W(mm) × H(mm) Overall dim 1720 × 1520 × 1760
Note: The rated capacity is the capacity when starch paste concentration is 5-7°Be’



Principle

PDSS type separator is mainly consists the feed device, rotating drum, cover, the body, horizontal shaft, vertical shaft, ground water pump, machine base, motor and other components.
When the rotating drum running a high speed, when the material enter into the disc separation area through the feeding pump (1), under the action of the centrifugal force field, the starch particles slip to the inside wall of the drum, discharged from the nozzle(4), and the light phase like protein and others will collect to the drum center, discharged out of the machine via centripetal pump(2).
The machine has a washing bottom pump, the washing water into the drum from the vertical center hole(7), it is used for washing the yellow paste of the starch material, and effectively improve the quality of starch.


Working Diagram

Peony Starch Separator With High Speed And Continuous Nozzle Discharge



Overall size and workflow diagram

Peony Starch Separator With High Speed And Continuous Nozzle Discharge
Peony Starch Separator With High Speed And Continuous Nozzle Discharge



Installation drawing

Peony Starch Separator With High Speed And Continuous Nozzle Discharge
H*H  B*B A K L a b c d
GB799-86
n*m
900*900 740*740 510 460 120 -550 -300 +100 +250 4-M20*500





Installation note:

1. Need sufficient space to install and maintainance
2. The install foundation should be smooth and fixed.
3. Between the foundation and frame, you have to install the vibration reducer gasket
4. All pipes connected with the machine should be the hose.





Packing:


Peony Starch Separator With High Speed And Continuous Nozzle Discharge





Guarantee:



Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time.
We are committed to reward you with a better quality in return for our interest in and faith toward.
We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
